The confidence of stopping power
A well-maintained braking system is crucial for a safe and successful drive. Pads, rotors and calipers will need to be repaired or replaced as part of regular brake service. But don’t worry, we have you covered. If you’re noticing signs of brake wear or are just looking for a routine inspection, visit your local Chevrolet dealer, where Chevrolet Certified Service experts can get confidently back on the road.
Are your brakes signaling a problem?
Sometimes, your Chevrolet vehicle’s brakes will alert you when there’s trouble. Whistling noises, chirping sounds, and grinding are indications that brake service is required. Here are some common causes of brake pedal pulsation and/or noise:
- Worn brake pads
- Heat-cracked or worn rotors
- Loose-fitting brake pads in the caliper
- Missing or damaged noise insulators
- Uneven torque of lug nuts or caliper hardware
Shop the GM Parts Store
Did you know you can now buy GM Genuine Parts or ACDelco parts straight from the source? The GM Parts Store is your one-stop shop for OEM parts online, designed for your vehicle and built to last. Buy the right parts for your vehicle from the comfort of home.
The life of a brake pad
Brake pad life depends on driving habits, vehicle usage, and operating environment. Brake systems are designed to provide 20,000 to 25,000 miles of pad life in very severe use (such as heavy-traffic urban areas) and will give 40,000 to 60,000 miles of pad life in average use. Factors that will reduce pad life include frequent heavy braking, elevated temperatures (caused by high-speed braking, driving in mountainous areas), driving with the vehicle heavily loaded, and severe environments such as high-corrosion areas and areas with a lot of road debris and dust.
A: Brake pads are equipped with wear indicators that produce a squealing noise when the brakes are almost worn out. The noise may be present with or without the brake pedal applied, but when noise is heard from the wear indicator, the brake pads should be replaced as soon as possible. Wear indicators are set to create noise when there is around 2 mm of brake pad friction material thickness remaining. In the case of assessing pad wear through inspection, pads should be replaced at or before 2 mm thickness is reached.
Brake rotors are marked with a “minimum thickness” on the casting (usually 2 mm to 3 mm less than the new rotor thickness). Rotors should be replaced before they reach this minimum thickness and should not be turned below this.
A: No. If there are no conditions such as pedal pulsation or steering-wheel vibration during braking, and the brake rotor is at least 1 mm thicker than the discard thickness, then it does not need to be turned or replaced.
A: Brake-pedal pulsation and other conditions such as steering-wheel shaking while braking are caused by thickness variation in the brake rotor When a thicker spot of the rotor rotates through the caliper, it pushes back against brake fluid, which can be felt at the brake pedal. The brake fluid and pedal then relax again as the thick spot exits the caliper. This process produces pedal pulsation and “brake torque variation,” which can shake the steering wheel and seats. Brake pulsation is not caused by warping of the disc. However, distortion of the disc due to excessive temperatures or improper installation and torqueing of the wheels can lead to brake rotor thickness variation over time. Brake-pedal pulsation is corrected by turning and/or replacing the brake rotors to eliminate the thickness variation.
A: Brake squeal is caused by the high-frequency vibration of brake components (rotor, calipers, and/or pads) in response to excitation from the brake friction process. A significant amount of time and engineering goes into eliminating brake squeal from original equipment brake components. Brake components are engineered as a complete system—factory-original performance can only be assured when using original equipment brake pads and rotors. When brake squeal occurs, there may be damage or excessive wear on one or more components affecting noise, including the brake pads, the noise-damping shim that is bonded to the brake pad, or the rotor friction surface.
In addition, it should be recognized that high-performance and track-capable brake systems using high-performance pad materials will always be at higher risk for producing brake squeal noise, even when no damage to the components is present.
A: Brake pad life depends on driving habits, vehicle usage, and operating environment. Brake systems are designed to provide 20,000 to 25,000 miles of pad life in very severe use (such as heavy-traffic urban areas) and will give 40,000 to 60,000 miles of pad life in average use. Factors that will reduce pad life include frequent heavy braking, elevated temperatures (caused by high-speed braking, driving in mountainous areas), driving with the vehicle heavily loaded, and severe environments such as high-corrosion areas and areas with a lot of road debris and dust.
A: Yes. Pads with higher metal content will tend to operate with more abrasive friction, where hard metal particles in the pad interact directly with the brake rotor surface. Use of metallic pads will create more brake dust and will shorten the rotor life. Non-asbestos organic pads (also known as ceramic pads) used on most GM vehicles in North America develop a transfer film, a layer of material on the pad and rotor surface that acts as a cushion (at a microscopic scale) between the brake pad and rotor, protecting both from abrasive interaction that causes wear.
A: Brake dust can occur to some extent on most brake systems, but it is significantly more noticeable with metallic pads and on high-performance brake systems. Brake dust is a mix of debris from the brake rotor, which is the most significant component, and debris from the brake pads. Pad materials that wear the rotor more aggressively will cause more dust.
A: There are often significant differences between original equipment and aftermarket brake rotors. While brake rotors designed to fit the same vehicle will often be similar in appearance and dimensions, there can be differences in internal cooling vane design, thickness of the brake plates (against which the brake pad rubs), and the grade and material specification of the cast iron. For original equipment brake rotors, significant analysis and testing goes into determining the right geometry to minimize thermal distortion and squeal noise and to maximize cooling. Similar rigor is put into the material selection, which also affects the risk of squeal noise as well as friction and wear properties.
